Cold Heading
Cold upsetting die materials are widely used in manufacturing industry. They are indispensable materials to achieve low cost in automotive, aviation and fastener industries, such as bolt forming dies, nut forming dies, universal joint extrusion dies, gear extrusion dies, parts upsetting forming dies and other cold (warm) forging dies.
Grades and physical Properties
Note: It is the representative data, not the guarantee value
Cold heading forming material——XR151、XR201、XR203、XR22C、XR25K
Features:
Adopting the mixed grain structure with good wear resistance and chipping resistance;
Application:
Fasteners, round bearing ball and other components used in automotive and mechanical industries；
Cold extrusion forming material ——XR18K、XR22K、XR25K
Features:
Adopting coarse particle tungsten carbide with excellent impact resistance;
The alloy has the corrosion resistance with the latest binding phase composition design. It is suitable for electric discharge machining.
Application:
Components used in the automotive industry like the cross shaft and bevel gear；
Heat forming material——XR151、XR18K、XR22K、XR25K
Features:
Using coarse-grained tungsten carbide, the alloy has excellent impact resistance;
The alloy has the corrosion resistance with the latest binding phase composition design. It is suitable for electric discharge machining.
Application:
Titanium alloy parts, transmission shaft, steering axle and other parts used in the automotive and aerospace industries.
Download
